SECTION 4 OPERATING INSTRUCTIONS
4-18 DD-29/31HF/38HF Vibratory Asphalt Compactors
Shutting Down the Machine
1. Move engine throttle control (13, Figure 4-27) to the Low Idle (Down) position.
2. If the machine is to be serviced or transported, place the articulation locking bar
(1, Figure 4-28) in the locked position.
3. Allow machine to idle for a few minutes before turning ignition switch to stop
position. Remove ignition key.
Figure 4-27
Figure 4-28
DAILY PRECAUTIONS AFTER WORK
Perform the following precautions each day after work in addition to the daily routine
maintenance on the lubrication chart.
1. Fill fuel tank to prevent condensation problems.
2. Clean drum scrapers of accumulated material.
3. If available, lock all vandal protection devices on the machine.
