SECTION 6 TROUBLESHOOTING
6-6 DD-29/31HF/38HF Vibratory Asphalt Compactors
FUSE TROUBLESHOOTING
Below is a fuse table containing electrical equipment and the associated fuse. If the fuse is not
blown, suspect defective wiring. If this is the case, call for service to correct.
SYMPTOM MALFUNCTION POSSIBLE CAUSE SOLUTION
Start Relay Fuse F1 Replace
Vibration Solenoids
Power Relay Coil
Fuse F2 Replace
Emergency Stop
Brake and Shunt Solenoids
Fuel Pump
2 Second Timer/Fuel Shut-OFF
Fuse F3 Replace
Horn
Indicator Lamps
Fuse F4 Replace
Water Pump Fuse F5 Replace
Work Lights Option Fuse F6 Replace
Back-Up Alarm Option Fuse F7 Replace
Beacon Option Fuse F8 Replace
Turn/Stop Lights Option Fuse F9 Replace
Optional Gauges Fuse F10 Replace
Audible Alarm Option Fuse F11 Replace
