MAINTENANCE INSTRUCTIONS SECTION 5
DD-29/31HF/38HF Vibratory Asphalt Compactors 5-19
2. Press and hold park brake test switch (8, Figure 5-20) and move propulsion
control (14, Figure 5-21) towards the Forward position to attempt machine
movement. If the parking brake system is functioning, the machine will not
move. If machine moves, contact service personnel and do not operate
machine.
Figure 5-21
Clean Water Strainer
Check the water spray system strainer (1, Figure 5-22) clean as necessary at this interval.
1. Park the machine on a level surface and turn OFF the engine. Turn OFF water
flow control (2, Figure 5-18).
2. Unthread clear plastic bowl (2, Figure 5-22) and remove strainer (1).
Figure 5-22
3. Rinse the strainer and bowl in clean water. If necessary use a soft bristle brush
for hard to remove deposits.
4. Be sure gasket is in place and reassemble the strainer and bowl.
