MAINTENANCE INSTRUCTIONS SECTION 5
DD-29/31HF/38HF Vibratory Asphalt Compactors 5-39
WARNING
!
Engine damage.
Raw, unfiltered air can cause engine damage.
Never service the air cleaner while the engine is running.
1. Open two clips (1, Figure 5-49) and remove air filter housing cover (2) to access
the filter elements. Check vacuator valve (3) to see that it is not inverted,
damaged or plugged. Clean inside housing cover (2) using a clean, damp cloth.
Figure 5-49
2. Gently remove primary filter element (1, Figure 5-50).
Figure 5-50
