SECTION 3 OPERATING CONTROLS AND INSTRUMENTS
3-4 DD-29/31HF/38HF Vibratory Asphalt Compactors
Figure 3-4
Refer to Figure 3-5 and Figure 3-6 for locations of the following controls:
Figure 3-5
Figure 3-6
12. Water Flow Control 13. Engine Speed Control (Throttle) Lever
14. Propulsion Control (F-S-R) Lever 15. Vibration ON/OFF Switch
