SECTION 4 OPERATING INSTRUCTIONS
4-24 DD-29/31HF/38HF Vibratory Asphalt Compactors
Figure 4-32
6. Open the hood and disengage the propulsion pump (1, Figure 4-33) by
pressing down on buttons (2).
Figure 4-33
NOTICE
Use only appropriate drawbars for towing requirement.
Maximum towing speed is 2.5 km/h (1.5 mph) and maximum towing
distance is 300 meters (984 feet).
7. Attach an appropriate towing vehicle using appropriate chains/drawbar which
can be secured in position at the selected tow points on the machine. Remove
the chocks.
8. Tow machine off site at a very slow speed for a short distance
(maximum 300 meters [984 feet]).
