SECTION 5 MAINTENANCE INSTRUCTIONS
5-10 DD-29/31HF/38HF Vibratory Asphalt Compactors
Figure 5-7
3. Clean the inside of the air cleaner housing before removing the safety element
(1, Figure 5-7).
4. Pull the safety air cleaner element (1, Figure 5-7) out of the housing. Dispose
of used element properly.
5. Carefully install the replacement safety element by pushing it straight into
housing.
6. Carefully install the cleaned or replacement primary element (1, Figure 5-8).
7. Install air cleaner cover (2, Figure 5-9) and secure with clips (1). Ensure all clips
are tight.
8. Inspect all air intake piping and joints between air cleaner and engine air inlet
to ensure no dusty air can enter.
Figure 5-8
