Example: Parts list for bus / towing vehicle (with external sensors WM2)
WABCO PART
NUMBER COMPONENT COMMENT 4X2 6X2
ARTICULATED
BUS 6X2
446 220 100 0 ECU Communication with trailer ECU /
warning lamps
1 1 1
446 220 000 4 Mount Support for mounting the ECU 1 1 1
446 221 000 0 Display Display of warning messages and
retrieving tire pressures
1 1 1
894 607 390 0
+ adapter
894 600 001 2
Wiring harness Cable set 7-pin
optional 894 607 295 0 (5-pin, no
trailer operation)
1 1 1
960 731 051 0 External sensor,
L-shape
For front axle, rim 22.5", 10 holes 2 4 2
960 731 031 0 External sensor For rear axle, rim 22.5", 10 holes 4 4 8
960 905 822 4 Weight plate Counterweights for front axle sensor 2 4 2
960 731 802 0 PA tube For front axle sensor, L-shape 2 4 2
960 731 822 2 PA tube For rear axle sensor, outside 2 2 4
960 731 804 0 PA tube For rear axle sensor, inside 2 2 4
960 731 801 0 PA tube Super Single 2 2 4
Example: Parts list for bus / towing vehicle (with internal sensor WIS)
WABCO PART
NUMBER COMPONENT COMMENT 4X2 6X2
ARTICULATED
BUS 6X2
446 220 100 0 ECU Communication with trailer ECU /
warning lamps
1 1 1
446 220 000 4 Mount Support for mounting the ECU 1 1 1
446 221 000 0 Display Display of warning messages and
retrieving tire pressures
1 1 1
894 607 390 0
+ adapter
894 600 001 2
Wiring harness Cable set 7-pin
optional 894 607 295 0 (5-pin, no
trailer operation)
1 1 1
960 732 000 0 Internal sensor Internal sensor to be attached to a
special valve set
6 8 10
960 732 100 0 Valve set Exact design of the valve depends on
the rim
6 8 10
