9.3 Module reception
In this menu item, the signal strengths of the individual sensors are queried and displayed. The display
can vary from weak signal strength (one bar) to strong signal strength (three bars).
1. Click on the Measured values menu item.
2. Select Module reception.
3. If no bar is displayed on an internal sensor, rotate the affected wheel so that the sensor points
toward the ECU. If there is still no sensor received, the distance to the ECU is too great and the
ECU must be installed elsewhere.
9.4 Assignment test
The conguration is checked to ensure that all entries including the sensor ID have been made correctly
during conguration. For this purpose, all sensors must be stimulated (see Chapter "9.2.3 Stimulating
the sensors", page 61).
1. Click Start to start the assignment test.
2. Stimulate the sensors according to the wheel position highlighted on the screen.
Ö The assignment test is completed after all sensors have been stimulated.
9.5 Finalising start-up
1. Delete content of diagnostic memory (start window: Messages - Diagnostic memory).
2. Print the start-up log, (Start-up window).
3. Print the vehicle label onto self-adhesive aluminium foil
(WABCO part number: 899 200 922 4) (Start-up window).
4. Attach the vehicle label to the vehicle where it is protected and legible.
5. Exit the start-up procedure in the diagnostic software.
6. Check operation on display and data exchange with towing vehicle respectively.
Ö Start-up is complete.
