Installation
7.9 Wiring in trailer
Proceed as follows to install the wires of the OptiTire into the trailer:
– Read Chapter "6.4 Connecting cables", page 32.
– Select the suitable circuit diagram (see Chapter "Wiring diagrams for trailers", page 16).
– Fit the diagnostic socket to a suitable attachment location and label it with "Diagnostic OptiTire".
Locations where diagnostic ports are already located would be specially suitable as the attachment
location.
– De-energise the trailer.
– Install cables according to the wiring diagram using cable ties in parallel with already existing wiring
harnesses. Form large loops from ample lengths.
– Connect OptiTire wiring to existing wiring.
– Connect the ECU.
