Components
6.7 WABCO TPMS Manager
WARNING
Danger from electromagnetic radiation
Electromagnetic and electronically generated waves can interfere with the operation of pacemakers.
– If you have a pacemaker, do not use this product.
Information and technical data
WABCO TPMS MANAGER
WABCO part number 300 200 001 0
Battery life approx. 400 operations per full charge
Dimensions (H x W x D) 16.5 cm x 9.5 cm x 3.8 cm
Housing material high impact ABS
Response frequency
Main frequencies: 315 MHz and 433.92 MHz (support of most specic
frequencies).
Low battery indication LCD bar display
Weight approx. 1 kg
Temperatures
Operation: -20 °C to +55 °C
Storage: -40 °C to +60 °C
Working height up to 2000 m
Purpose and function
The WABCO TPMS Manager can be used to stimulate and read all types of WABCO tire pressure
sensors (WM2, WIS and SMS). Data such as temperature, pressure, lifetime of internal batteries, IDs,
etc. can be read out.
The WABCO TPMS Manager can be congured in different languages via its menu.
Supported units:
UNIT BAR KILOPASCAL POUND PER QUARTER INCH
Celsius bar / °C kPa / °C PSI / °C
Fahrenheit bar / °F kPa / °F PSI / °F
To control the internal sensor SMS, you may need to update the software version on the WABCO TPMS
Manager.
