Operation
10.7 Display via SmartBoard
WABCO SmartBoard
WABCO part numbers
446 192 110 0 / 446 192 210 0 (with integrated battery)
446 192 111 0 / 446 192 211 0 (for hazardous goods vehicles)
The SmartBoard is a display and operating console that can be used to display the following information
relating to the OptiTire system:
 System conguration, such as part number, software version, serial number, production date and
vehicle identication number (VIN)*
 Nominal values and actual value pressures
 Tire status (OK/not OK)
 ID of a sensor (if the sensor is activated with a solenoid)**
 ECU data
*VIN is only displayed with 446 192 110 0 and 446 192 111 0.
**The complete VIN is only displayed with 446 192 210 and 446 192 211 0.
