WABCO OptiTire - Page 35

35
Components
6.5 Cable sets
Connecting cables
with open end
L
Part Number
L
[m]
Cable ends type
449 376 070 0 7
open
7-strand with push-on
contacts and PG screw
connection
7 x 0.5 mm²
Bayonet socket
7-pin
449 376 250 0 25
for TEBS E (subsystem)
L
Part Number
L
[m]
Cable ends type
449 913 050 0 5
Bayonet socket
7-pin
Code C
8-pin
for TEBS E (subsystem) and SmartBoard
SMART
BOARD
IVTM
L1
L2
Part Number
L1
[m]
L2
[m]
Cable ends type
449 916 182 0 0.4 4
2x bayonet socket
7-pin
Code C
8-pin
449 916 243 0 1 6
449 916 253 0 6 6
for TEBS E (subsystem), OptiLink™ and SmartBoard
L1
L2
L3
L4
L5
Part Number
L1
[m]
L2
[m]
L3
[m]
L4
[m]
L5
[m]
Cable ends type
449 934 330 0 12 1 4 0.5 6
2x HDSCS
8-pin
Code C
8-pin
+ bayonet
socket
7-pin
for TEBS E (subsystem), OptiLink™ and control box
L1
L2
L3
L4
Part Number
L1
[m]
L2
[m]
L3
[m]
L4
[m]
Cable ends type
449 944 217 0 12 4.5 6 0.5
2x HDSCS
8-pin
+ bayonet
socket
7-pin
Code C
8-pin
