Components
Bus cable set, 5-pin
L2
L3
L1
1000
2000
Part Number
L1
[m]
L2
[m]
L3
[m]
Cable ends type
894 607 295 0 9 2.5 2
Bayonet socket
7-pin
Plug
Display
+ diagnosis
socket with blue
cap
7-pin
+ open
4-strand
4 x 0.5 mm²
Cable set towing vehicle, 7-pin
L2
L3
L1
1000
2000
Part Number
L1
[m]
L2
[m]
L3
[m]
Cable ends type
894 607 390 0 9 2.5 2
Bayonet socket
7-pin
Plug
Display
+ diagnosis
socket with blue
cap
7-pin
+ open
5-strand
5 x 0.5 mm²
for diagnosis
L
Part Number
L
[m]
Cable ends type
449 601 060 0 6
Diagnosis
socket with blue cap
7-pin
open
4-strand with push-on
contacts and PG screw
connection
4 x 0.5 mm²
