Introduction
1.2 Machine overview
Abb. 1: Machine outside views
1 Lights
2 Boom light
3 Handhold
4 Auxiliary hydraulics
5 Lifting eye/tie-down point
6 Door arrester
7 Door handle and lock
8 Rotating beacon
9 Rear light
10 Exhaust pipe
11 Lubrication point for track tension
12 Engine air intake
4
5
6
8
9
2
4
7
10
3
5
1
1
8
12
