Wacker Neuson E09-01 User Manual

6-12 BA 1404 en – Edition 2.7 * * 1404b610.fm
Technical data
6.14 Lift capacity table with long stick (Standard chassis and canopy) (option)
All table indications in kg (lbs) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The compact excavator’s lift capacity is restricted by the settings of the pressure limiting
valves and the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
Abb. 221: Lift capacity table
A max. 3.0 m (9'-10") 2.0 m (6'-7")
B
Across stabilizer
blade
Across
side 360°
Across stabilizer
blade
Across
side 360°
Across stabilizer
blade
Across
side 360°
Lowered Raised Lowered Raised Lowered Raised
1.5 m
(4‘11”)
390*
(860*)
170
(375)
160
(353)
415*
(915*)
185
(408)
175
(386)
375*
(827*)
355
(783)
335
(737)
1.0 m
(3'-3")
375*
(827*)
155
(342)
150
(330)
425*
(937*)
175
(386)
170
(375)
575*
(1268)
325
(717)
305
(672)
0.5 m
(1‘8”)
360*
(794*)
150
(331)
145
(320)
410*
(904*)
170
(375)
165
(364)
695*
(1532*)
290
(639)
275
(606)
0.0 m
(0'-0")
345*
(761*)
155
(342)
145
(320)
400*
(882*)
190
(419)
180
(397)
695*
(1532*)
270
(595)
255
(562)
max Permissible load on extended stick
A Reach from live ring center
B Load hook height
* Lift capacity limited by hydraulic system
