6-8 BA 1404 en – Edition 2.7 * * 1404b610.fm
Technical data
6.11 Dimensions
1462 (4'10'')
3648 (12')
1065 (3'6'')
1250 (4'1'')
1300 (4'3'')
2283 (7'6'')
990 (3'3'')
980 (3'3'')
230 (9'')230 (9'')
215 (8.5'')
235 (9.3'')
270 (10.6'')
3606 (11'10'')
Abb. 218: Machine dimensions
1300 (4'3'')
990 (3'3'')
287 (11'') 432 (1'5'')
1195 (3'11'')
R1075 (3'6'')
49°
73°
