3-56 BA 1404 en – Edition 2.7 * * 1404b330.fm
Operation
Assembly
Tighten hexagon head screws A (M6/8.8) to 10 Nm (7 ft.lbs) on the left and right.
Tighten hexagon socket screws B (M20/8.8) to 410 Nm (302 ft.lbs) on the left and right.
Abb. 124: Protective FOPS structure category I (assembly at
front)
A
Abb. 125: Protective FOPS structure category I (assembly at
rear)
B
