WAGNER Cobra 40-10 Original Operating Manual

51
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
Order No. Designation
A 2329519 Diaphragm pump Cobra 40-10
1 322912 Hydraulic oil (for pressure stage) 250 ml; 250 cc
2 236219 Grounding cable 3 m; 9.8 ft
3 2382997 AirCoat lter pressure regulator
4 341434 Double open-end wrench
6 2329026 Inline lter, HL DN6-PN270-G1/4"-SSt
7 2325343 Fitting, DF-MM-R1/4"-M12-PN270-SSt
8 2341068 Fitting, SF-FF-G3/8-G1/4-530 bar-SSt
9 2331273 Fitting, EF-FM-G1/4-G1/4-530 bar-SSt
10 2332621 Fitting RF-FM-G3/8-1/4NPSM-530 bar-SSt
11 2323325 Air suction lter DN25
12 2329046 Return hose DN6-PN310-G1/4"-PA
13 2324116 DN25 suction hose
14 2333163 Return tube for item 15
15 2344505 5-liter hopper set for Cobra
16 2328611 AirCoat regulator set
17 2324110 DN16 suction hose
18 2330774 Fitting, DF-MM-G1/4-1/4NPSM-530 bar-SSt
19 2332620 Fitting RF-FM-G3/8-3/8NPSM-530 bar-SSt
20 322052 Frame, complete
21 2332143 Wall mount 4", complete
22 2349756 Wall mounting long
24 2323396 Air suction lter DN16
25 2325901 Trolley 4", complete
26 2344741 2 L tank for Cobra
27 2341278 20 L tank for Cobra
28 2345265 Exhaust pipe 20L
29 3767 Filter disk D51
30 2304620 Drum cover 365-B
31 2304439 Drumcover 365-E
32 2341375 Cobra trolley, complete
33 2324558 Inline lter DN6-PN270-G1/4"-SSt
34 2332619 Fitting RF-FM-G1/4-1/4NPSM-530 bar-SSt
51 322911 Oil lling set with 100 ml; 100 cc syringe
52 322916 Air coupling set DN 10 mm; 0.39 inch
53 9985619 Hose connector with sealing ring
55 2329922 Fitting SF-MM-G3/8"-M24-PN530-SSt
56 2335334 HP lter DN12-PN530-CS, complete
57 2330775 Fitting, DF-MM-G3/8-G3/8-530 bar-SSt
58 9974112 Sealing ring for G3/8 thread
= Wearing parts.
Regarding item 7: Fitting (7) can be screwed in instead of the relief valve. In this case, the required ball valve
must be provided by the customer. The return hose can no longer be connected to the "return socket" output.
