WAGNER Cobra 40-10 Original Operating Manual

64
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
14.7 COBRA 4025
73
B_04257
1
2
3
5
6
7
8
9
10
11
14
100
99
98
97
96
95
94
18
93
17
35
33
34
32
31
15
16
46
47
49
50
41
101
27
102
26
66
67
38
40
91
19
69
20
21
22
23
24/92
25
67
26
102
27
4
71
13
100 Nm; 74 lbft (8 x)
120 Nm; 89 lbft (2 x)
50 Nm; 37 lbft
2 Nm; 1.5 lbft
105
104
20 Nm; 15 lbft
20 Nm
14.8 lbft
40 Nm; 29.5 lbft
110
110
110
110
110
110
72
28
17
81
80
104
1.5 Nm; 1.1 lbft
1 1 2329898 Sealing sleeve
2 4 9900204 Hexagon screw
3 4 9920102 Washer
4 2 341241 Inlet valve depressor, complete, see Chapter 14.9
5 1 2330795 Inlet housing
6 8 2306195 Hexagon screw
7 8 9925011 Washer
8 2 2306183 O-ring
