WAGNER Cobra 40-10 Original Operating Manual

80
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
14.21 2 LITER TANK
4
2
10
8
6
1
B_05018
7
3
5
11
9
* Replace for the following pumps:
− Cobra 40-10 with date of product before November 2013.
Order No. Designation
1 2344741 2L Cobra tank
1 1 2320844 Union nut with bayonet
2 1 2321426 Low-pressure mini ball valve, G1/2
3 1 2341277 2 l tank
4 1 2341532 Cover
5 2 2321676 Sieve insert SPA easy line
6 1 2320888 Cone connector preassembled
7 1 9990623 Protection plug
8 1 2320922 Sealing sleeve
9 1 2333163 Exhaust pipe 2L / 5L assy.
10 1 2347181 Assembly Manual
11* 1
2330810 Connection piece
= Wearing part.
