27
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
6.5.1 VENTILATION OF THE SPRAY BOOTH
Operate the device in a spray booth approved for the working materials.
- or -
Operate the device on an appropriate spraying wall with the ventilation (extraction)
switched on.
Observe national and local regulations for the exhaust air speed.
6.5.2 AIR SUPPLY LINES
Ensure that only dry, clean atomizing air is used in the spray gun! Dirt and moisture in the
atomizing air worsens the spraying quality and spray pattern.
WARNING
Hose connections!
Risk of injury and damage to the device.
Do not mix up hose connections of product hose and air hose.
6.5.3 PRODUCT SUPPLY LINES
DANGER
Bursting hose, bursting threaded joints!
Danger to life from injection of product.
Ensure that the hose material is chemically resistant to the sprayed products.
Ensure that the spray gun, ttings and product hose between the device and the
spray gun are suitable for the pressure generated in the device.
Ensure that the following information can be seen on the high-pressure hose:
- Manufacturer
– Permissible operating pressure
- Date of manufacture
6.6 GROUNDING
WARNING
Discharge of electrostatically charged components in atmospheres containing
solvents!
Explosion hazard from electrostatic sparks.
Clean the pump only with a damp cloth.
WARNING
Heavy paint mist if grounding is insucient!
Danger of poisoning.
Insucient paint application quality.
Ground all device components.
Ground the work pieces to be coated.
