WAGNER Cobra 40-10 Original Operating Manual

38
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
8.2.6 CLEANING AND REPLACING THE FILTER
8.2.6.1 STRAIGHT INLINE FILTER 270 BAR
1. Flush the pump and inline lter in accordance with
Chapter 7.5. Flush using the gun so that the ushing agent
ows through the inline lter. Maximize the ow (remove
the nozzle, open the dosing valve if necessary).
B_05274
2
3
5
1
**
Anti-seize paste**
Flow direction
27MPa; 270bar; 3916psi
2. Empty the pump in a controlled manner in accordance
with Chapter 8.2.4.
3. Place the grounded collection tank under the inline lter.
4. If no swivel joint is mounted, remove the hose.
5. Unscrew the inlet housing (2) and outlet housing(5) with
two size 19 wrenches.
6. Remove the lter insert (3).
7. If the inline lter has any leaks, replace the seal* (1).
8. Insert the new lter insert* (3). Note the installation
position: Closed end in direction of ow.
9. If necessary, coat the thread with anti-seize paste**.
10. Screw together the inlet housing (2) and outlet housing (5)
with two size 19 wrenches.
11. If necessary, screw the hose back on.
12. Fill the pump in accordance with Chapter 8.2.5.
* Order No., see Chapter 13.
** Order No., see Chapter 10.3.
8.2.6.2 ANGLED INLINE FILTER 270 BAR
1. Flush the pump and inline lter in accordance with
Chapter 7.5. Flush using the gun so that the ushing agent
ows through the inline lter. Maximize the ow (remove
the nozzle, open the dosing valve if necessary).
B_05273
4
1
**
2
3
5
Anti-seize paste**
Flow direction
27MPa; 270bar; 3916psi
2. Empty the pump in a controlled manner in accordance
with Chapter 8.2.4.
3. Place the grounded collection tank under the inline lter.
4. Unscrew the lter by turning the handle (4).
5. Remove the lter insert (3).
6. If the inline lter has any leaks, replace the seal* (1).
7. Insert the new lter insert* (3). Note the installation
position: Closed end in direction of ow.
8. If necessary, coat the thread with anti-seize paste**.
9. Assemble the turning handle (4), inlet housing (2) and
outlet housing(5) and tighten by turning the handle.
10. Fill the pump in accordance with Chapter 8.2.5.
* Order No., see Chapter 13.
** Order No., see Chapter 10.3.
