WAGNER Cobra 40-10 Original Operating Manual

65
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
Order No. Designation
9 2 2306164 Valve tting
10 2 341336 Clasp
11 1 2308753 Inlet valve set, complete (comprising 2 valves), see Chapter 14.8
13 1 2330810 Connection piece
14 1 2337668 Fluid section
15 2 2308868 Flange connection
16 2 2308886 O-ring
17 1 169248 Relief valve, complete (for spare parts, see Chapter 14.11)
18 1 2308760 Outlet valve set, complete (spare parts for 2 valves)
19* 1 2330775 Fitting, DF-MM-G3/8-G3/8-530 bar-SSt
19* 1 2330780 Fitting, DF-MM-G1/2-G3/8-530 bar-SSt
20 1 2308754 Complete Cobra 40-25 diaphragm kit with insert (comprising 2 diaphragms)
21 2 9904306 Screw plug
22 2 9970127 Sealing ring
23 1 2337746 Pressure stage
24 3 9907041 Hexagon screw
25 1 2306251 Piston rod D25/70
26 2 9941502 Ball
27 2 9971189 O-ring
28 1 2334842 Pressure relief valve
29 1 2306146 Permaglide bushing
30 1 2308870 Pressure stage ange
31 2 2306143 Rod sealing prole BS
32 2 2306144 Rod sealing set
33 2 2306145 O-ring
34 2 9971446 O-ring
35 2 2306139 Pressure disk
37 1 115944 O-ring
38 1 2352719 Oil tank set
40 1 9998274 Threaded plug G1/4
41 1 2306196 Piston cover
46 1 2308869 Pressure stage cover disk
47 1 2306142 O-ring
49 4 9907124 Hexagon screw
50 4 9920106 Washer
51
1 2386160 Self-locking hexagon nut (new)
1 9910101 Hexagon nut, secured with Loctite® 243 (old version!)
53 2 322427 Damping washer
54 1 2306204 Piston sealing prole Z5
55 1 2306205 Piston air motor 4
57 1 9974084 O-ring
58 2 9920107 Washer
59 1 9974090 Seal wiper ring, prole EM
60 1 2344073 Air motor ange
61 1 367258 Grounding, complete
62 1 369290 Pilot valve
63 2 9998675 Threaded plug
66 1 9998780 Pressure spring
67 2 322407 Oil valve screw
68 1 9971162 O-ring
69 2 2306179 Insert
70 1 9974217 Rod seal
71 2 9971486 O-ring (solvent-resistant)
72 2 341316 Scraper
73 1 9971395 O-ring, 10x1.25
80 1 2339251 Plug
