WAGNER Cobra 40-10 Original Operating Manual

57
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
Order No. Designation
10 1 367310 Silencer 4
11 1 9974098 O-ring
12 1 9974097 O-ring
13 3 9900325 Socket cap screw
14 3 9920103 Washer A6.4
15 1 367309 Connecting part 4
16 2 367320 Cotter pin
17 1 369290 Pilot valve
18 2 9998674 Threaded plug
19 1 9998274 Threaded plug
20 1 2359165 Control housing 4
21 1 367313 Compressed air lter 4/6
22 1 2328606 Pressure regulator unit 4
24 1 9990506 Cone plug, GPN 600
25 1 9999228 Screw connector L
26 2 367307 Sealing plug, 4/6
27 2 9974085 O-ring
28 1 367324 Filter holder
29 1 367314 Control air lter
30 1 322910 Cobra outlet seal set (consisting of 2 seals)
31 2 9974095 O-ring
32 1 368285 Safety valve 0.63 MPa; 6.3 bar; 91 psi
33 1 9943080 Spool and sleeve assembly, complete
34 1 368038 Detent body, complete, ISO 1/2
35 2 9907126 Screw SFS Plastite 45
36 2 9974089 O-ring
37 2 9974115 O-ring
38 1 322432 Control air pipe
39 1 322430 Cylinder pipe
40 1 322431 Compressed air pipe
41 2 9971448 O-ring
42 1 2360756 Edge ball valve 4, cpl.
43 1 9971137 O-ring
44 4 9900316 Hexagon socket head cap screw M6x50
45 2 9907039 Hexagon socket head cap screw M6x80
46 1 9971313 O-ring
47 1 2341175 Manometer with air regulator 0-10 bar, G1/8"
48 1 2309972 Pressure regulator
49 1 2309744 Distributor LR-D-I Mini 4
50 2 9974166 O-ring
51 1 9904307 Locking screw with collar / hexagon socket
52 1 9974217 Rod seal
53 1 9970154 Sealing ring
54 1 322439 Air motor noise insulation
55 1 9990861 Ribbed plug
56 2 368313 Damper ISO1 and ISO2
57 6 9971123 O-ring
58 1 9992590 Loctite 222 50 ml; 50 cc
59 1 9992831 Loctite 542 50 ml; 50 cc
60 1 9992616 Molykote DX grease
61 1 9992528 Loctite 270 50 ml; 50 cc
2341627 Cobra 40-10 air motor service set
= Wearing part.
= Included in service set.
