71
VERSION 01/2018
ORDER NUMBER DOC 2340851
Cobra 40-10 / 40-25
Ball valve version in carbon steel
Order No. Designation
1 1 2335334 HP lter DN12-PN530, complete
2 1 2324542 Filter housing
3 1 2324543 Union nut
4 1 2330780 Fitting, DF-MM-G1/2-G3/8-PN530-SSt
5 1 9955863 O-ring
7 1 2324670 Distribution housing for ball valve
10 1 9894245 Filter support
11 1 Filter sieve *
295721 * Filter sieve 200
3514068 * Filter sieve 100
3514069 * Filter sieve 50
291564 * Filter sieve 20
12 1 3514058 Cone spring
20 1 9998679 Ball valve
21 1 2325562 Pressure ring d45
23 1 2323718 Hexagon plug
33 1 2325826 Double connector
34 1 9992831 Loctite 542 50 ml; 50 cc
35 1 9998808 Mobilux EP2 grease
36 1 9992609 Anti-seize paste tube
= Wearing part.
= Not part of the standard equipment but available as a special accessory.
