Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
5 Description
Order number 2340851 | Edition 05/2022 21
5.2.2 Fluid Section
The fluid section (9) has been designed as a double diaphragm pump with exchangeable
inlet and outlet valves. Change between spraying mode and product circulation mode using
the relief valve (7).
5.3 PROTECTIVE AND MONITORING EQUIPMENT
WARNING
Overpressure!
Danger to life from bursting device components.
4 Never change the safety valve setting.
The air motor is fitted with a safety valve. The safety valve has been set and sealed at the
factory. In case of pressures over and above the permissible operating pressure, the valve,
which is held with a spring, automatically opens and releases the excess pressure.
The control housing is equipped with noise insulation. Never operate the device without
noise insulation.
5.4 EXTENT OF DELIVERY
Stk Order no. Designation
1 2329519 Diaphragm pump Cobra 40-10 consisting of:
Fluid section, air motor, connection elements
1 2329521 Frame-mounted diaphragm pump Cobra 40-10 consisting of:
Fluid section, air motor, connection elements
1 2329523 Diaphragm pump Cobra 40-25 consisting of:
Fluid section, air motor, connection elements
1 2329525 Frame-mounted diaphragm pump Cobra 40-25 consisting of:
Fluid section, air motor, connection elements
The standard equipment includes:
Stk Order no. Designation
1 322981 Sign
1 236219 Grounding cable, complete
1 341434 Double open-end wrench
1 See Chapter Declaration of Conformity
[895]
Declaration of Conformity
1 2340850 Operating manual, in German
1 See Chapter Languages [87] Operating manual in the local lan-
guage
The delivery note shows the exact scope of delivery. Accessories: see Chapter Accessories
[860].
