Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
14 Spare Parts
94 Order number 2340851 | Edition 05/2022
14.21 2 LITER TANK
4
2
10
8
6
1
B_05018
7
3
5
11
9
Pos K Stk Order no. Designation
1 2344741 2L Cobra tank
1 1 2320844 Union nut with bayonet
2 ♦ 1 2321426 Low-pressure mini ball valve, G1/2
3 1 2341277 2 Liter Tank
4 1 2341532 Cover
5 ♦ 2 2321676 Sieve insert SPA easy line
6 1 2320888 Cone connector preassembled
7 1 9990623 Protection plug
8 ♦ 1 2320922 Sealing sleeve
9 ♦ 1 2333163 Relief pipe 2L/5L, complete
10 1 2347181 Assembly manual
11* 1 2330810 Connection piece
♦ = wearing parts
* Replace for the following pumps:
– Cobra 40-10 with date of product before November 2013.
