13 Accessories
Order number 2340851 | Edition 05/2022 63
Regarding item 7: Fitting (7) can be screwed in instead of the relief valve. In this case, the
required ball valve must be provided by the customer. The return hose can no longer be
connected to the [return socket] output. Alternative: Item 65 includes a ball valve.
Regarding item 56:When using the HP filter (item 56), the respective appropriate fitting
must be used (for product output fluid sections 1/2", the two fittings items 55 and 59 are
required; for product output fluid sections 3/8", only fitting item 55 is required). The suitable
sealing ring (item 60/61) must also be used.
Regarding items 55/57/58/59: When the fitting is replaced at the product output (items
55/57/58/59), a new sealing ring (item 60/61) must also be installed.
Pos K Order no. Designation
A 2329523 Diaphragm pump Cobra 40-25
1 ♦ 322912 Hydraulic oil (for pressure stage) 250 ml; 250 cc
2 ♦ 236219 Grounding cable 3 m; 9.8 ft
3 2382997 AirCoat filter pressure regulator
4 341434 Double open-end wrench
6 2329026 Inline filter HL DN6-PN270-G1/4"-SSt
7 2325343 Fitting, DF-MM-R1/4"-M12-PN270-SSt
8 2341068 Fitting, SF-FF-G3/8-G1/4-530bar-SSt
9 2331273 Fitting, EF-FM-G1/4-G1/4-530bar-SSt
10 2332621 Fitting, RF-FM-G3/8-1/4NPSM-530bar-SSt
11 2323325 Air suction filter DN25
12 2329046 Return hose DN6-PN310-G1/4"-PA
13 2324116 DN25 Suction Hose
14 2333163 Return tube for item 15
15 2344505 5-liter hopper set for Cobra
16 2328611 AirCoat regulator set
17 2324110 DN16 Suction Hose
18 2330774 Fitting, DF-MM-G1/4-1/4NPSM-530bar-SSt
19 2332620 Fitting, RF-FM-G3/8-3/8NPSM-530bar-SSt
20 2308732 Cobra 40-25 frame
21 2332143 Wall mount 4", complete
22 2349756 Wall mounting, long
24 2323396 Air suction filter DN16
25 2325901 Mobile base 4", complete
27 2341278 20 liter tank
28 2345266 Exhaust pipe 20L
29 ♦ 3767 Filter disk D51, 400 μm
♦ 3768 Filter disk D51, 800 μm
30 2304620 Drum cover 365 B
31 2304439 Drumcover 365-E
32 2341375 Cobra mobile base, complete
33 2324558 Inline filter DN6-PN270-G1/4"-SSt
34 2332619 Fitting, RF-FM-G1/4-1/4NPSM-530bar-SSt
51 ♦ 322911 Oil filling set with 100 ml; 100 cc syringe
