Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
14 Spare Parts
68 Order number 2340851 | Edition 05/2022
Pos K Stk Order no. Designation
8 1 367318 Shoulder screw 4
9 1 9925033 Washer
10 1 367310 Silencer 4
11 ♦ ⋆ 1 9974098 O-ring
12 ♦ ⋆ 1 9974097 O-ring
13 3 9900325 Socket cap screw
14 3 9920103 Washer, A6.4
15 1 367309 Connecting part 4
16 2 367320 Cotter pin
17 ♦ 1 369290 Pilot valve
18 2 9998674 Threaded plug
19 1 9998274 Threaded plug
20 1 2359165 Control housing 4
21 ♦ ⋆ 1 367313 Compressed air filter 4/6
22 1 2328606 Cobra pressure regulator unit, complete
24 1 9990506 Cone plug, GPN 600
25 1 9999228 Fitting L
26 2 367307 Sealing plug 4/6
27 ♦ ⋆ 2 9974085 O-ring
28 1 367324 Filter holder
29 ♦ ⋆ 1 367314 Control air filter
30 ♦ ⋆ 1 322910 Cobra outlet seal set (consisting of 2 seals)
31 ♦ ⋆ 2 9974095 O-ring
32 1 368285 Safety valve 0.63 MPa; 6.3 bar; 91 psi
33 ♦ 1 9943080 Spool and sleeve assembly, complete
34 ♦ 1 368038 Detent body, complete, ISO 1/2
35 2 9907126 Screw SFS Plastite 45
36 ♦ ⋆ 2 9974089 O-ring
37 ♦ ⋆ 2 9974115 O-ring
38 1 322432 Control air pipe
39 1 322430 Cylinder pipe
40 1 322431 Compressed air pipe
41 ♦ ⋆ 2 9971448 O-ring
42 ♦ 1 2360756 Angled ball valve 4, complete
43 ♦ ⋆ 1 9971137 O-ring
44 4 9900316 Hexagon socket head cap screw, M6x50
45 2 9907039 Hexagon socket head cap screw, M6x80
46 ♦ ⋆ 1 9971313 O-ring
47 ♦ 1 2341175 Pressure gauge with air regulator 0-10 bar, G1/8"
48 ♦ 1 2309972 Pressure regulator
49 1 2309744 Distributor piece LR-D-I Mini 4
