Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
14 Spare Parts
76 Order number 2340851 | Edition 05/2022
Pos K Stk Order no. Designation
8 1 367318 Shoulder screw 4
9 1 9925033 Washer
10 1 367310 Silencer 4
11 ♦ ⋆ 1 9974098 O-ring
12 ♦ ⋆ 1 9974097 O-ring
13 3 9900325 Socket cap screw
14 3 9920103 Washer, A6.4
15 1 367309 Connecting part 4
16 2 367320 Cotter pin
17 1 369290 Pilot valve
18 2 9998674 Threaded plug
19 1 9998274 Threaded plug
20 1 2359165 Control housing 4
21 ♦ ⋆ 1 367313 Compressed air filter 4/6
22 1 9970154 Sealing ring
24 1 2328608 Cobra 6 pressure regulator unit, complete
25 1 9904307 Locking screw with collar/hexagon socket
26 2 9990506 Cone plug, GPN 600
27 ♦ ⋆ 2 9974085 O-ring
28 1 367324 Filter holder
29 ♦ ⋆ 1 367314 Control air filter
30 ♦ ⋆ 1 322910 Cobra outlet seal set (consisting of 2 seals)
31 ♦ ⋆ 2 9974095 O-ring
32 1 368285 Safety valve 0.63 MPa; 6.3 bar; 91 psi
33 ♦ 1 9943080 Spool and sleeve assembly, complete
34 ♦ 1 368038 Detent body, complete, ISO 1/2
35 2 9907126 Screw SFS Plastite 45
36 ♦ ⋆ 2 9974089 O-ring
37 ♦ ⋆ 2 9974084 O-ring
38 1 367305 Control air pipe
39 1 2306127 Cylinder pipe
40 1 367304 Compressed air pipe
41 ♦ ⋆ 2 9971448 O-ring
42 ♦ 1 2391704 Edge ball valve midi to size 4
43 ♦ 1 2309973 Pressure regulator valve LR-1/2-D-O-Midi
44 ♦ 1 2341176 Pressure gauge with air regulator 0-10 bar, G1/4"
47 1 9999228 Elbow screw-in connection R1/2 - G1/2
48 ♦ ⋆ 1 3105540 O-ring
49 ♦ ⋆ 1 9971018 O-ring
50 1 M396.00 Reducing fitting
52 ♦ 1 9974217 Rod seal
