Operating manual High-pressure double diaphragm pumps Cobra 40-10; Cobra 40-25
14 Spare Parts
Order number 2340851 | Edition 05/2022 81
Pos K Stk Order no. Designation
109 1 2314670 Piston rod assembly pin
110 1 9992616 Molykote ® DX grease
111 1 9998808 Mobilux ® EP 2 grease
♦ = wearing parts
⋆ = Included in service set
* The internal thread at the product output of the fluid section (item 14) will be converted as
of 2014 from G1/2" to G3/8", please use the corresponding fitting and sealing ring (see
chapter Accessories [860]).
105
109
51
53
54
55
53
57
59
60
61
62
70
63
58
58
B_04256
40 Nm; 29.5 lbft
111
111
29
59
30
31
15
16
32
33
34
35
Note: The piston rod (25) may only be mounted with the screwed-on assembly pin (109).
Grease all O-rings and seals lightly with grease (111) before mounting them.
