55
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Spare parts list air motor 100 mm / stroke 150 mm 150 mm / stroke 150 mm
4 / stroke 6 inches 6 / stroke 6 inches
Designation Order No. Order No.
1 Air motor 1 2329619 1 2329623
2 Flange 1 367316 1 368316
3 Piston rod 1 367402 1 368402
4 Cylinder pipe 1 367403 1 368403
5 Compressed air pipe 1 367404 1 368404
6 Control air pipe 1 367405 1 367405
8 Sealing plug 2 367307 2 367307
9
Outlet seal 2 L414.06C 2 L423.06
10 Connecting part 1 367309 1 368309
11 Silencer 1 367310 1 368310
12 Hood 1 367311 1 368311
13 Filter, compressed air 1 367313 1 367313
14 Control air lter 1 367314 1 367314
15 Fluid warning label 1 2332082 1 2332082
16 Shoulder screw 2 367318 2 368324
17 Sound deadening pad 1 367319 1 368319
18 Cotter pin 2 367320 2 368320
20 Pressure regulator 1 9998676 1 9999506
20
Pressure regulator XR-15
(special accessory)
– 1 9999554
23 Filter holder 1 367324 1 367324
25 Throttle – 1 367325
28
O-ring 6 9971123 6 9974142
29 Rod seal 2 9974217 2 9974217
30 Pilot valve 2 369290 2 369290
31 Spool and sleeve assembly 1 9943080 1 9943081
32 Permaglide bushing 1 9962018 1 9962019
= Wearing part
= Included in service set
Incorrect maintenance/repair!
Risk of injury and equipment damage.
Have repairs and part replacements be carried out only by
specially trained sta or a WAGNER service center.
Before all work on the device and in the event of work
interruptions:
- Switch o the energy/compressed air supply.
- Relieve the pressure from the spray gun and device.
- Secure the spray gun against actuation.
Observe the operating and service instructions at all times when
carrying out work.
WARNING
