WAGNER Puma User Manual

56
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Spare parts list air motor 100 mm / stroke 150 mm 150 mm / stroke 150 mm
4 / stroke 6 inches 6 / stroke 6 inches
Designation Order No. Order No.
33 Piston 1 9998661 1 9998662
34 Seal wiper ring 1 9974090 1 9974091
35 Safety valve 1 368288 1 368287
36
O-ring 2 9974084 2 9974087
37 O-ring 2 9974085 2 9974085
39 O-ring 2 9974089 2 9974089
40 O-ring 2 9974095 2 9974096
41 O-ring 2 9971448 2 9971137
42 O-ring 1 9974097 1 9974100
43 O-ring 1 9974098 1 9974101
44 Threaded plug 2 9998674 2 9998674
45 Threaded plug 2 9998274 2 9998274
46 WAGNER label 1 2330370 1 2330372
47 Threaded plug 2 9998675 2 9998675
48 Control housing 1 367315 1 368315
49 Washer 2 9920106 2 9925026
50 Hexagon bolt 3 9907121 3 9907121
51 Hexagon nut 1 9910101 1 9910605
52 Washer 3 9920106 3 9920106
53 Washer 1 9920107 2 9920110
54 SFS screw 2 9907126 3 9907125
55 Socket screw 3 9900325 3 9900313
56 Washer 3 9920103 3 9920102
57
Sealing ring 1 9970149 1 9970149
58 Base 1 9952668 1 9952668
59 Clamping bracket 1 9952667 1 9952667
60 Socket screw 1 9900701 1 9900701
61 Spring ring 1 9921505 1 9921505
69 Drive fastener 1 9998718 1 9998718
71 IceBreaker label 1 2330382 1 2330382
72 Warning label 1 2332077 1 2332077
74
Detent element complete ISO 1/2 368038 1 368038
75 Damper ISO 1/2 2 368313 2 368313
81 Spool & sleeve assembly ISO1 or ISO2 1 9943097 1 9943098
100
Pressure regulator unit, complete
(incl. pos. 62)
1 2328606 1 2328606
106 Loctite 222 50 ml; 50 cc 1 9992590 1 9992590
107 Loctite 243 50 ml; 50 cc 1 9992511 1 9992511
108 Loctite 542 50 ml; 50 cc 1 9992831 1 9992831
109 Molykote DX grease 1 9992616 1 9992616
110 Grease Beacon 1 9998808 1 9998808
Service set 1 367995 1 368995
= Wearing part
= Included in service set
