61
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Jaguar air motor spare parts list
220 mm / stroke 150 mm
8.7 inches / stroke 6 inches
Designation Order No.
31 1 Spool and sleeve assembly 369907
32 1 Permaglide bushing 9962019
33 1 Piston 9 369385
34
1 Seal wiper ring 9974125
35 1 Safety valve 368286
36 2 O-ring 9974133
37 2 O-ring 9971056
39 2 O-ring 9974089
40 2 O-ring 9974132
41 4 O-ring 9971137
43 1 O-ring 9974165
46 1 WAGNER label 2330372
47 2 Threaded plug 9998675
48 1 Control housing 369315
49 1 Washer 9925034
50 4 Hexagon bolt 9907137
51 1 Hexagon nut 9910605
52 4 Washer 9920106
53 2 Washer 369303
54 7 SFS screw 9907125
55 3 Socket screw 9900314
56 3 Washer 9925029
57
1 Sealing ring 9970149
58 1 Base 9952668
59 1 Clamping bracket 9952667
60 1 Socket screw 9900701
61 1 Spring ring 9921505
71 1 IceBreaker label 2330382
72 1 Warning label 2332077
74
1 Detent body 369027
75 1 Rod seal pro le E5 9974124
76 2 Elbow screw-in connection 9992757
77 1 Screw connector T 9992758
78 4 Washer 9920102
79 4 Socket screw 9900313
80 2 Washer 9925031
81 1 Lifting eye nut 369325
= Wearing part
= Included in service set
