62
OPERATING MANUAL
VERSION 02/2013 ORDER NUMBER DOC 2333548
Jaguar air motor spare parts list
220 mm / stroke 150 mm
8.7 inches / stroke 6 inches
Designation Order No.
82 1 Shoulder ring 369324
83 1 Hexagon bolt 9900150
84 1 O-ring 9974262
85 1 Air pipe 369306
87 3 O-ring 9971004
88 2 Damping washer 369304
89 1 Control ange 369317
90 1 Air hose back 369026
91 1 Air hose front 369025
92 1 Lock space 9 369326
93 2 Damper ISO 3 369329
94 1 Spool & sleeve assembly ISO3 9943131
95 1 Velcro fastener adhesive part 9999151
96 1 Velcro fastener coating part 9999152
97 1 Adhesive 9992816
98 1 Viton B O-ring 9971372
103 1 Schalldämmmatte 9/12" 369330
105 1 Pressure regulator unit 9, complete 2328609
106 1 Loctite 222 50 ml; 50 cc 9992590
107 1 Loctite 243 50 ml; 50 cc 9992511
108 1 Loctite 542 50 ml; 50 cc 9992831
109 1 Anti-sieze paste 9992616
110 1 Grease beacon 9998808
114 1 Piston 9 with SOFT O-ring 369971
1 Service set 369987
= Wearing part
= Included in service set
