114 Commissioning WAGO-I/O-SYSTEM 750
750-882 Media Redundancy ETHERNET Controller
Manual
1.5.0
8.2.5.2 Determining IP addresses
1. If the PC is already integrated into an IP network, you can determine the
PC's IP address by clicking on Control Panel from the Start Menu /
Settings.
2. Double-click on the Network icon.
The network dialog window appears.
For Windows 2000/XP:
• Select Network and Dial-Up Connections
• In the dialog window that then appears, right click on LAN Connection
and open the Properties link.
• Mark the entry Internet Protocol (TCP/IP)
For Windows 7:
• Choose Network and Sharing Center by using Control Panel.
• In the dialog window that then appears, right click on LAN Connection
and open the Properties link.
• Mark the entry Internet Protocol V4
For Windows 8 and higher:
• Choose Network and Internet >> Network and Sharing Center by
using Control Panel.
• In the dialog window that then appears, click on “Connections:” LAN
Connection and open the Properties link.
• Confirm the security prompt with [Yes].
• Mark in the Properties window / register Network the entry Internet
Protocol V4.
Reinstall TCP/IP components if required!
If the “Internet Protocol Version 4 (TCP/IPv4)” entry is missing, install the
corresponding TCP/IP components and reboot your computer.
You will need the installation CD for Windows 2000, XP or 7.
3. Then click on the Properties... button
4. The IP address, subnet mask and, where required, the PC's gateway
address appear in the Properties window. Note these values:
PC IP address: _ _ _ . _ _ _ . _ _ _ . _ _ _
Subnet mask: _ _ _ . _ _ _ . _ _ _ . _ _ _
Gateway: _ _ _ . _ _ _ . _ _ _ . _ _ _
5. Now select the desired IP address for your fieldbus node.
