WAGO-I/O-SYSTEM 750 Appendix 433
750-882 Media Redundancy ETHERNET Controller
Manual
1.5.0
Table 501: WAGO MIB – Process Image Group
Identifier
Entry
Access
Description
1.3.6.1.4.1.13576.10.1.50.8.1.3
wioModuleType
R
Type of module
1.3.6.1.4.1.13576.10.1.50.8.1.4
wioModuleCount
R
Count of module
1.3.6.1.4.1.13576.10.1.50.8.1.5
wioModule-
AlternativeFormat
R
Module in alternative format
1.3.6.1.4.1.13576.10.1.50.8.1.6
wioModuleAnalog-
OutLength
R
Length of analog output data of module
(Bit)
1.3.6.1.4.1.13576.10.1.50.8.1.7
wioModuleAnalog-
InLength
R
Length of analog input data of module
(Bit)
1.3.6.1.4.1.13576.10.1.50.8.1.8
wioModuleDigital-
OutLength
R
Length of digital output data of module
(Bit)
1.3.6.1.4.1.13576.10.1.50.8.1.9
wioModuleDigital-
InLength
R
Length of digital input data of module
(Bit)
16.2.18 Plc Data Group
The Plc data group contains values that can be used for data exchange with
CODESYS.
Table 502: WAGO MIB – Plc Data Group
Identifier
Entry
Access
Description
1.3.6.1.4.1.13576.10.1.100.1
wioPlcDataTable
-
1.3.6.1.4.1.13576.10.1.100.1.1
wioPlcDataEntry
-
1.3.6.1.4.1.13576.10.1.100.1.1.1
wioPlcDataIndex
R/W
Number of plc data DWORD
1.3.6.1.4.1.13576.10.1.100.1.1.2
wioPlcDataReadArea
R/W
Readable plc data (DWORD)
1.3.6.1.4.1.13576.10.1.100.1.1.3
wioPlcDataWriteArea
R
Write-/readable plc data DWORD)
