260 Fieldbus Communication WAGO-I/O-SYSTEM 750
750-882 Media Redundancy ETHERNET Controller
Manual
1.5.0
12.2.5.5 Firmware Information Registers
The following registers contain information on the firmware of the controller:
Table 168: Register Address 0x2010
Register address 0x2010 (8208
dec
) with a word count of 1
Firmware index, e.g. 0x0005 for version 5
Table 169: Register Address 0x2011
Register address 0x2011 (8209
dec
) with a word count of 1
WAGO serial number, e.g. 0x02EE (750 dec.) for WAGO-I/O-SYSTEM 750
Table 170: Register Address 0x2012
Register address 0x2012 (8210
dec
) with a word count of 1
First part of WAGO order number,
e.g. 0x0349 (841 dec.) for the controller 750-841 or 0x0155 (341 dec.) for the
Table 171: Register Address 0x2013
Register address 0x2013 (8211
dec
) with a word count of 1
Major sub item code, INFO_MAJOR
Firmware version major revision
Table 172: Register Address 0x2014
Register address 0x2014 (8212
dec
) with a word count of 1
Minor sub item code, INFO_MINOR
Firmware version minor revision
Table 173: Register Address 0x2020
Register address 0x2020 (8224
dec
) with a word count of up to 16
Description, INFO_DESCRIPTION
Information on the controller, 16 words
