90 Function Description WAGO-I/O-SYSTEM 750
750-882 Media Redundancy ETHERNET Controller
Manual
1.5.0
Figure 42: Example declaration of remanent flags by „var retain“
This breakdown can be varied (see following explanation).
NOVRAM memory allocation can be changed in WAGO-I/O-PRO!
The breakdown of the NOVRAM can be modified when required in the
programming software WAGO-I/O-PRO/Register "Resources"/Dialog window
"Target system settings".
The start address for the flag area is fixed. The area sizes and the start address
for the retain memory can be varied.
We do recommend keeping the standard settings, however, in order to avoid any
overlapping of the areas.
In these default settings the size of the flag area is set at 16#4000, followed by
the retain memory, with the size 16#4000.
