268 Fieldbus Communication WAGO-I/O-SYSTEM 750
750-882 Media Redundancy ETHERNET Controller
Manual
1.5.0
12.3.5.2 Class Overview
CIP classes are included in the CIP specification of ODVA. They describe the
properties (Volume 1, “Common Industrial Protocol”) of Ethernet and CAN
independent of their physical interface. The physical interface is described in a
separate specification. For EtherNet/IP, this is Volume 2 (“EtherNet/IP Adaptation
of CIP”), which describes the adaption of EtherNet /IP to CIP.
For this purpose, WAGO uses classes 01
hex
, 02
hex
, 04
hex
, 05
hex
, 06
hex
and F4
hex
,
which are described in Volume 1 (“Common Industrial Protocol”).
Classes F5
hex
and F6
hex
are supported from Volume 2 (“EtherNet/IP Adaptation of
CIP”).
WAGO-specific classes listed in the overview table below are also available.
All CIP Common classes listed and the WAGO-specific classes listed below that
are described in detail in the following individual sections after a brief explanation
of the table headings in the object descriptions.
Table 188: CIP common class
Class
Name
01
hex
Identity
02
hex
Message Router
04
hex
Assembly
05
hex
Connection
06
hex
Connection Manager
F5
hex
TCP/IP Interface Object
F6
hex
Ethernet Link Object
Table 189: WAGO specific classes
Class
Name
64
hex
Coupler/Controller Configuration Object
65
hex
Discrete Input Point
66
hex
Discrete Output Point
67
hex
Analog Input Point
68
hex
Analog Output Point
69
hex
Discrete Input Point Extended 1
6A
hex
Discrete Output Point Extended 1
6B
hex
Analog Input Point Extended 1
6C
hex
Analog Output Point Extended 1
6D
hex
Discrete Input Point Extended 2
6E
hex
Discrete Output Point Extended 2
6F
hex
Analog Input Point Extended 2
70
hex
Analog Output Point Extended 2
71
hex
Discrete Input Point Extended 3
72
hex
Discrete Output Point Extended 3
