Instance 511 ... 765 (Analog output value 511 up to 765)
Table 272: Analog Output Point Extended 2 (70
hex
) – Instance 511...765
Attribute ID
Access
Name
Data type
Description
Default
value
1
Get
AopObj_Value
ARRAY of
BYTE
Analog Output
-
2
Get
AopObj_Value_
Length
USINT
Length of the output data
AopObj_Value (in byte)
-
Common Services
Table 273: Analog Output Point Extended 2 (70
hex
) – Common service
Service
code
Service available
Service name
Description
Class
Instance
0E
hex
Yes
Yes
Get_Attribute_Single
Supplies contents of the appropriate
attribute
10
hex
No
Yes
Set_Attribute_Single
Modifies an attribute value
12.3.5.28 Analog Output Point Extended 3 (74
hex
)
The extension of the “Analog Output Point” class enables the exchange of data
from a fieldbus node that contains over 765 analog output points (AOPs). The
instance scope of the “Discrete Output Point Extended 3” class covers AOPs
from 766 to 1020 in the fieldbus node.
Instance 0 (Class Attributes)
Table 274: Analog Output Point Extended 3 (74
hex
) – Class
Attribute ID
Access
Name
Data type
Description
Default
value
1
Get
Revision
UINT
Revision of this object
1 (0x0001)
2
Get
Max Instance
UINT
Max. number of instances
-
Instance 766 ... 1020 (Analog output value 766 up to 1020)
Table 275: Analog Output Point Extended 3 (74
hex
) – Instance 766...1020
Attribute ID
Access
Name
Data type
Description
Default
value
1
Get
AopObj_Value
ARRAY of
BYTE
Analog Output
-
2
Get
AopObj_Value_
Length
USINT
Length of the output data
AopObj_Value (in byte)
-
