Installation manual
487 14 59 11 - TD30 TD50 TD75 US
10
Electrical Information
It is your responsibility to have ALL electrical connections (including grounding) made by a properly
licensed and competent electrician to assure that the electrical installation is adequate and conforms
with local and state regulations or codes.
In the absence of such codes, ALL electrical connections, material, and workmanship must
conform to the applicable requirements of the NATIONAL ELECTRIC CODE ANSI/NFPA NO. 70 or
the CANADIAN ELECTRICAL CODE, CSA C22.1 - both the latest edition.
IMPORTANT: Failure to comply with these codes or ordinances and/or the requirements
stipulated in this manual can result in personal injury or component failure.
NOTE: Component failure due to improper installation will VOID THE WARRANTY.
IMPORTANT: A separate circuit serving each dryer must be provided. The dryer must be
connected to copper wire only. DO NOT use aluminum wire which could
cause a fire hazard.
NOTE: The use of aluminum wire will VOID THE WARRANTY
CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors
can cause improper operation or component failure.
Electric Service
Steam and gas dryers ONLY
IMPORTANT:
The dryer must be connected to the electrical supply shown on the data
label affixed to the dryer. In the case of 208 VAC or 240 VAC, the supply
voltage must match the electric service specifications of the data label
exactly. Wire must be properly sized to handle the rated current.
WARNING: 120 VAC, 208 VAC and 240 VAC ARE NOT THE SAME. Any damage
done to dryer components due to improper voltage connections will
VOID THE WARRANTY.
Electric dryers ONLY
IMPORTANT:
ALL electrically heated dryers must be connected to the electric supply
service shown on the dryers data label which is affixed to the back side of
the control (service) door. The connecting wires must be properly sized to
handle the rated current.
NOTE: Component failure due to improper voltage application will VOID THE WARRANTY.
To Next Page
