1-8 Setting up the 2545 Binary Gradient Module
Rear panel of 2545 Binary Gradient Module
3. Insert the other end of the power cord into a grounded power receptacle.
Key
Number Name
1
Power entry module
2 Fuse holder
3 Ethernet RJ45 port
4 Connector A
5 Connector B
3
4
5
2
1
