5-62 Maintenance Procedures

3. Remove the probe end cover assembly.

4. Unscrew and remove the nebulizer adjuster knob to reveal the PEEK

union and UNF coupling.

Nebulizer adjuster knob

PEEK Union

UNF coupling
