5-90 Maintenance Procedures

Air filter tab

3. Use a vacuum cleaner to clean the air filter.

Air filter removed from behind the source probe

4. Reinstall the air filter.

5. Fit the probe to the source.

RP00023

Air filter tab

TP02637

Air filter

Frame
