Waters 3100 - Installing the Reservoir Bottles

Preparing the IntelliStart Fluidics system 2-7
Installing the reservoir bottles
An optional Low-volume Adaptor Kit is available for infusing smaller
volumes. The low-volume vials have a volume of 1.5 mL.
Required material
Chemical-resistant, powder-free gloves
To install the reservoir bottles
1. Remove the reservoir bottle caps.
2. Screw the reservoir bottles onto the instrument, as shown below.
To install low-volume vials
1. If a standard reservoir bottle is fitted, remove the reservoir bottle.
2. Screw the low-volume adaptor into the manifold and tighten it
finger-tight.
Warning: The reservoir bottles can be contaminated with
biohazardous and/or toxic materials. Always wear
chemical-resistant, powder-free gloves while performing this
procedure.
Warning: The reservoir bottles can be contaminated with
biohazardous and/or toxic materials. Always wear
chemical-resistant, powder-free gloves while performing this
procedure.
TP02630
