Connecting to the nitrogen gas supplyB-19
Gas and exhaust connections
5. Attach a nitrogen regulator (not provided) to the nitrogen supply.
6. Install the 6-mm stud into the regulator outlet.
7. Connect the free end of the long piece of 6-mm PTFE tubing to the 6-mm
stud.
RP00001
01757 U.S.A.
!
!
V ~ 200 - 240V ~ 200 - 240
Hz 50 - 60Hz 50 - 60
VVA 900
ACN 065444751
1
2
3
4
5
6
7
8
9
10
Analog
Not used
Stop Flow
Switch 2
Ground
Ground
Out
Out
1
2
3
4
5
6
7
8
9
10
Inject Start
Event
Switch 3
Switch 4
Ground
Ground
In
In
Out
Out
Out
RS 232RS 232
ETHERNETETHERNET
API GasAPI Gas
6.9 Bar Maximum6.9 Bar Maxim um
SOURCE VENTSOURCE VENT
VACUUMVACUUM
VACUUMVACUUM
PUMPPUMP
Serial Number
Source
vacuum
Source vent
Turbo vacuum
Nitrogen inlet
