Figure 3–2: Unscrewing cap nut from fitting
Cap nut
Fitting
2. Slide the fitting off the tubing.
Figure 3–3: Sliding fitting off tubing
Tubing
Fitting
Result: The ferrule unlocks from the fitting.
3. Remove the ferrule from the fitting.
Figure 3–4: Removing ferrule from fitting
