D.9 Connecting the workstation
Before connecting the workstation to the instrument, set up the workstation according to its
accompanying instructions. Locate the workstation within 5 meters (16 feet) of the instrument.
Requirement: Use shielded network cables with the instrument to ensure compliance with FCC,
and other, limits.
To connect the workstation:
1. Connect the peripherals to the PC.
2. Connect one end of the shielded network cable to the ethernet port on the rear panel of the
instrument.
3. Connect the other end of the cable to the ACQUITY ethernet switch box.
4. Connect one end of another shielded network cable to the ACQUITY ethernet switch box.
5. Connect the other end of the cable to the port labeled Instrument LAN on the workstation
rear panel.
To connect the instrument to the power source:
1. Select the correct power cord for your location.
2. Connect the female end of the power cord to the power port on the rear panel of the
instrument.
Warning: To avoid injury from electrical shock or fire, and damage to the equipment, do not place
vessels containing liquid atop the workstation or ancillary equipment or otherwise expose those
units to dripping or splashing liquids.
Prohibited: Do not place vessels containing liquid—such as solvent bottles—atop the
workstation or ancillary equipment or otherwise expose those units to dripping or splashing
liquids.
Notice: Do not connect the instrument’s power supply cord until you complete the
installation procedures in the previous sections.
